Enable oled on Geekworm PiKVM-A4 Kit | Geekworm

Enable oled on Geekworm PiKVM-A4 Kit

tS

teamjang Shin
1/29/23, 3:12 PM
1. Edit /boot/config.txt and add below codes.
```
dtparam=i2c1=on
dtparam=i2c_arm=on
```
2. Edit /etc/modules-load.d/raspberrypi.conf and add below code.
```
i2c-dev
```
3. install package
```
pacman -S i2c-tools
```
4. enable oled-service
```
systemctl enable --now kvmd-oled kvmd-oled-reboot kvmd-oled-shutdown
```
5. reboot
```
reboot now
```
1 likes 0 likes

5
Posts

808
Views
HH

Harry Huang Staff member
1/30/23, 11:08 AM

Thanks for your valuable post;
Need to ask you, which OS do you use?

0 likes 0 likes
tS

teamjang Shin
1/30/23, 1:08 PM

@Harry Huang

I said PiKVM-A4 kit that is used for rpi-zero 2w.

It means I used v2-hdmi-zero2w-lastest.img.xz.

0 likes 0 likes
KC

Kim Coles
5/4/23, 6:39 PM
@cubes 2048
1. Edit /boot/config.txt and add below codes.
```
dtparam=i2c1=on
dtparam=i2c_arm=on
```
2. Edit /etc/modules-load.d/raspberrypi.conf and add below code.
```
i2c-dev
```
3. install package
```
pacman -S i2c-tools
```
4. enable oled-service
```
systemctl enable --now kvmd-oled kvmd-oled-reboot kvmd-oled-shutdown
```
5. reboot
```
reboot now
```
Thank you for sharing. It is what I am looking for.
0 likes 0 likes
